Test 1/4 Fuel Hose Quick Connector

Test 1/4 Fuel Hose Quick Connector
Test 1/4 Fuel Hose Quick Connector
Previous
Next
OEM No/Model:

1/4 fuel connector

Minimum Order:

1Set/Sets

Place of Region:

CHINA

Market Type:

After Market

Current Export Market:

Product Details

Product Name:

Test 1/4 Fuel Hose Quick Connector

Product Attribute:

Application:

All Car

Product Description:

Item: Plastic quick connector Size: Ø6.3 ,1/4" Hose fitted: Tube ID x OD 3x5 mm Material:PA12/PA66 +30%GF SAE Fuelconnector working environment 1. Gasoline and diesel fuel delivery systems, ethanol and methanol delivery systems or their vapor venting or evaporative emission control systems. 2. Operating pressure 500kPa, 5bar, (72psig) 3. Operating vacuum -50kPa, -0.55bar, (-7.2psig) 4. Operating temperatures from -40℃ to 115 ℃, short time 150 Alwaytec quick connectors are supplied with orings and plastic material combinations, To determine correct choices,pls advise us which the liquid medium will it carry. Need More and Newest SAE Quick connector,pls send inquiy to us. Also welcome cusmade.

Test 1/4 Fuel Hose Quick Connector
Test 1/4 Fuel Hose Quick Connector
